Only Their Mother Can Tell Them Apart
Original Post - 07 Nov 2019 - Michael H. Scott
Visit Structural Analysis Is Simple on Substack.
In January 1999, when OpenSees was known as G3, Prof. Fenves created G2 for teaching nonlinear structural analysis in CE 221 at UC Berkeley. G2 was written in MATLAB with an architecture similar to G3.
I took CE 221 and used G2 for the homework assignments, but after a few years I lost the code. Oh well, these things happened in the days before cloud-based storage.
I wrote G2 off as G3’s long lost sibling, reminiscent of the 1988 film Twins starring Arnold Schwarzenegger and Danny DeVito as twins separated at birth after a genetic experiment yielded unexpected results.
Fast forward to October 2019. One of my good graduate school friends invited
me to give a seminar at his university. After the seminar, we got to talking
about OpenSees, then the conversation turned to CE 221 and G2. I asked my friend
if he kept the G2 source code and he said “Yes, it’s right here on my laptop.”
After wiping away my amazement at his archiving skills, I offered up a memory
stick and he dragged and dropped.
After I returned home, I took a trip down memory lane. G2 includes linear-elastic, small displacement truss and beam-column elements and there are a couple of material nonlinear truss elements. The material nonlinear beam-column elements include the two-component model and displacement-based and force-based distributed plasticity formulations. Fiber-discretized cross-sections are implemented for wide-flange shapes with bilinear stress-strain response. There is also a geometrically nonlinear elastic truss element.
Newton-Raphson and Modified Newton are the available solution algorithms. These can
be used with a variable step load-control static integrator. It’s MATLAB, so the solver
is the \ operator–no need for options there.
Considering G2 was written for MATLAB v5.0, I was a little surprised it ran so smoothly on MATLAB v9.5 (R2018b). The only hiccup was adding the G2 directory to the MATLAB path.
To ensure I don’t lose the G2 code again, I created a GitHub repository after securing the appropriate permissions. You can read more about the element formulations and solution strategies in the source files. Clone it, fork it, give it a try–it may be useful for your research. I’ll accept pull requests if you would like to share examples or contribute new functionality.
The title of this post is taken from the tagline of Twins. Here is the scene where
the twins see each other for the first time since birth.
